CNC titanium hlau peeling tshuab
Yantai Haige Tshuab Cov cuab yeej Co., Ltd. yog tsim nyob rau hauv 1999, uas tau ua hauv steel hlau xov khoom, xws li titanium hlau peeling tshuab, Series JY Bar Straightening Tshuab, Abrasive Siv Gear, Teeb Tshuab, Txhaj Blasting Tshuab, Centerless Sib Tsoo Tshuab, CNC skiving thiab cov neeg siv tshuab Burnishing tshuab thiab tshuab raj lwm yam. Peb kuj koom hauv nruam tawv chrome plating khoom thiab cov khoom siv tshuaj kho kub.
Raws li 15 xyoos kev tsim thiab tsim kev, peb cov cav tov tau raug xa mus rau Xwm Ciam Tebchaws Vietnam, Is Nrias teb, Pakistan, Iran, Sab Qab Teb Kauslim, Qaum Teb Kauslim, Taiwan thiab lwm lub teb chaws thiab cheeb tsam.
Titanium hlau tshuab peeling yog ib yam ntawm peb cov khoom tseem ceeb, uas yog siv los so tshem tawm cov xeb ntawm cov tawv dub ntawm titanium hlau ua cov titanium xaim dub. Lub tshuab siv lub tshuab muaj lub txaj, cov kabmob tseem ceeb, cov roj / lubrication system, lub hauv ntej-clamping pinch noj thiab kev pabcuam hauv qab-clamping, nyob rau hauv phau ntawv qhia thiab nruab nrab-rear qhia system, lub ntsiab tsav tsheb thiab lwm yam. ntawm cov twj tso kua roj hmab, yeeb nkab, tshuab raj thiab lwm yam. Lub tshuab phaj chip tshem tshuab yog cov khoom sib txuam ua los ntawm cov tuam txhab ua haujlwm. Peeling nti ntog mus rau lub phaj ntawm nti tshem tawm cov cuab yeej thiab yog sau los ntawm siv nqa.
qauv | WXC30C | |
khoom yuav tsum tau | inch kab (mm) | 6.5 |
khoom ntev (hli) | ≥1400 | |
yield zog (Mpa) | ≤1100 | |
txheej tawv hardness | ≤HB320 | |
straightness (hli / m) | ≤1.5 | |
lub siab kam | raws li GB 702-2004 thib ob pab pawg | |
puag ncig (hli) | ≤ 50% ntawm lub siab kam | |
saum npoo qhov roughness (Ra) | ≤ 25 ~ 50μm | |
tiav khoom | inch kab (mm) | 6 xyoo 30 |
txoj kab nruab nrab ntawm qhov tob (hli) | 0.5 ~ 1.0 | |
lub siab kam | ≤h10 | |
saum npoo qhov roughness (Ra) | ≤6.3μm | |
pub ceev ceev (m / min) | 1.0 ~ 8.0 | |
txiav taub hau kev sib hloov ib feeb (rpm) | 900 ~ 2000 | |
lub cev muaj zog (kw) | 30 | |
tag nrho cov peev xwm (kw) | 50 | |
compressed cua (npaj los ntawm tus neeg siv) | 0.5 ~ 0.8MPa, 1.8m3 / min, 0.8 m3 pem huab cua tank nrog ob theem roj dej separator thiab compressed cua freezing hom tshuab drying | |
